User Manual / QIG

1. Safety Precautions

• Install devices only by trained personnel.
• Disconnect power before wiring or maintenance.
• Use certified accessories, mounts, and power supplies.
• Do not expose devices to water unless rated for outdoor use.
• Test all components regularly.

---

2. Camera Manual

2.1 Overview

The camera provides real-time video surveillance for indoor/outdoor security applications.

2.2 Features

• High-definition video capture
• Infrared night vision
• Motion detection
• Remote monitoring via mobile/PC
• Weatherproof housing (if outdoor type)

2.3 Installation

1. Mounting
   • Select a stable surface with a clear field of view.
   • Fix the mounting bracket and attach the camera.
2. Power Connection
   • Connect to 12V DC adapter or PoE (Power over Ethernet) depending on model.
3. Network Setup
   • Connect via LAN cable or configure Wi-Fi using the mobile app/software.
4. Angle Adjustment
   • Adjust tilt and pan for optimal coverage.

2.4 Operation

• View live feed through the mobile app/NVR/software.
• Enable features such as motion alerts, recording schedules, and playback.

2.5 Maintenance

Update firmware regularly.

Clean the lens monthly with a microfiber cloth.

Check power/network cables periodically.

3. Smoke Sensor Manual

3.1 Overview

The smoke sensor detects early signs of fire through smoke particles and triggers an alarm signal to the control panel.

3.2 Features

• Photoelectric smoke detection
• LED status indicator
• Automatic reset
• Low-battery warning (in battery models)

3.3 Installation

1. Install on the ceiling, at least 1 meter away from corners and air vents.
2. Avoid locations near kitchens, bathrooms, or dusty areas.
3. Connect to power (wired) or insert battery (battery model).
4. Link to fire alarm panel if required.

3.4 Operation

• Normal Mode: LED blinks periodically.
• Alarm Mode: Continuous siren + red LED.
• Fault Mode: Intermittent beep (for contamination or low battery).

3.5 Testing & Maintenance

• Press the Test button weekly.
• Replace batteries every 12 months.
• Clean sensor vents every 3 months with a soft brush.

Hooter (Alarm Siren) Manual

4.1 Overview

The hooter is a high-decibel audio alarm used to alert occupants during emergencies.

4.2 Features

• 90–120 dB loud alarm
• Indoor/outdoor variants
• Continuous or pulsed tone (depending on model)

4.3 Installation

1. Mount on a wall at a height of 2–3 meters.
2. Connect to 12V/24V DC or system relay output.
3. Ensure correct polarity: Red (+), Black (–).

4.4 Operation

• Activates automatically when receiving a trigger from the fire/security panel.
• Can also be manually activated by the panic switch or control system.

4.5 Maintenance

• Test monthly by triggering from the control panel.
• Ensure wiring terminals are free from corrosion.

5. Panic Switch Manual

5.1 Overview

The panic switch is a manual emergency device used to instantly trigger an alarm or notify monitoring personnel.

5.2 Types

• Push Button
• Break-Glass Type
• Latch/Reset Type

5.3 Installation

1. Mount at accessible height (1–1.2 meters from floor).
2. Connect to control panel terminals (NO/NC depending on type).
3. Ensure wiring uses shielded cables for false-alarm prevention.

5.4 Operation

• User presses the switch to instantly generate an emergency alarm.
• For break-glass type, break the glass and press the internal button.
• For latch type, reset must be done manually at the panel/switch.

5.5 Maintenance

• Test weekly to verify alarms are received.
• Replace broken glass immediately (for break-glass type).
• Inspect wiring for wear or damage.
